Triangle with hook with knuckles

Extruded fibre concrete spacer with isosceles triangular section with knuckles

Length

18 cm

33 cm

Code Concrete cover Pieces per Pallet Weight per Piece (KG) Weight per Pallet (KG) Pieces per bag Bags per pallet
DHN1820 20 5000 0,15 770,000 125 40
DHN1825 25 5000 0,16 820,000 125 40
DHN1830 30 5000 0,18 920,000 125 40
DHN1835 35 4000 0,20 820,000 100 40
DHN1840 40 4000 0,30 1220,000 100 40
DHN1845 45 3200 0,32 1044,000 80 40
DHN1850 50 2000 0,43 880,000 50 40
DHN1855 55 1800 0,45 830,000 45 40
DHN1860 60 1600 0,50 820,000 40 40
DHN1865 65 1600 0,55 900,000 40 40
DHN1870 70 1400 0,60 860,000 35 40
DHN1875 75 1000 0,70 720,000 25 40
Code Concrete cover Pieces per Pallet Weight per Piece (KG) Weight per Pallet (KG) Pieces per bag Bags per pallet
DHN3325 25 3000 0,27 830,000 75 40
DHN3330 30 3000 0,29 890,000 75 40
DHN3335 35 2400 0,40 980,000 60 40
DHN3340 40 2000 0,50 1020,000 50 40
DHN3345 45 1600 0,55 900,000 40 40
DHN3350 50 1280 0,70 916,000 32 40
DHN3355 55 1000 0,75 770,000 25 40
DHN3360 60 1000 0,95 970,000 25 40
DHN3365 65 800 1,00 820,000 20 40
DHN3370 70 800 1,05 860,000 20 40
DHN3375 75 700 1,15 825,000 20 35

Note

  • Suitable for vertical reinforcements
  • Quick and easy application thanks to the galvanized harmonic steel hook
  • Excellent for exposed surfaces thanks to the toothed base
  • Other lengths and specifications available upon request
